Do High-frequency PCBs Have Better Performance?

Most of the high-frequency PCBs are used in the communication electronics industry, with the rapid progress of the electronics industry, in the fields of air transportation, satellite systems, etc., the application of high-frequency PCBs has become a reality that does not have to be changed. So what are the basic requirements for the material characteristics of high-frequency PCB it board production factories when selecting PCB substrates?

Dielectric constant: Dk needs to be small and stable, under normal circumstances, the smaller the Dk, the faster the signal transmission speed, inversely proportional to the square root of the dielectric constant of the substrate, the larger the dielectric constant, the easier it is to cause signal transmission delay.

Dielectric loss: At the same time, the smaller the Dk, the better the signal transmission quality, the smaller the dielectric loss, and the smaller the signal loss.

The thermal expansion coefficient of copper foil should be consistent as much as possible, and the water absorption should be low. Other heat resistance, chemical resistance, impact strength, peel strength, and other aspects must be well protected. Normally, the definition of a high-frequency board is above 1GHz, most of the high frequency PCB substrates currently produced are fluorine-based dielectric substrates, such as Teflon, most of which are used above 5GHz, and other FR-4 substrates are used between 1GHz ~ 10GHz.

Frequency characteristics Teflon is the best choice, if the product frequency is really higher than 10GHz, only Teflon can meet, of course, not all high-frequency PCBs must choose Teflon materials, the specific situation depends on the customer’s demand for products to decide.

The specific five characteristics of the high-frequency PCB:

(1)Benefits: high frequency PCBs and low-frequency power supply circuits are both voltage gain and output power harvesting effects, resonant differential amplifier circuit, it refers to the resonant frequency f0, for optical fiber broadband differential amplifier circuit, it refers to a frequency area.

(2)Passband: the concept of low-frequency power supply circuit board is good, for the resonant differential amplifier circuit, most of them refer to the value between the two corresponding frequencies when the normalized vibration amplitude drops to 0.707 for the resonant frequency f0; for the optical fiber broadband amplification circuit, it refers to the corresponding meaning relative to a certain frequency.

(3) Selectivity: Selectivity is mainly for resonant amplification circuits, which characterize the circuit’s selection of useful signals and the suppression ability of useless signals, which is usually measured according to the resonance characteristic curve of the circuit, with rectangular coefficient and suppression ratio.

(4) Noise figure: When the amplification circuit is working, due to some factors, the fluctuations will move irregularly, and the noise formed inside the circuit will affect the quality of the signal. This effect is usually described as the ratio of signal power PS to noise power PN (SNR). The noise factor is the contrast between the input signal noise and the output signal noise.

(5) Stability: The stability of high frequency PCB refers to the stability of its main performance when the working state or working conditions change. When the temperature of the environment changes or the voltage of the power supply fluctuates, it will affect the normal state of the Dc operation of the amplified circuit, and the parameters of the circuit components will also change, which will lead to the change of the gain of the amplification circuit, the frequency shift of the center, and the sudden change of the resonance curve. In the end, it can lead to not working at all.
